Hobbywing SKYWALKER 2826SL 1100KV Airplane Brushless Motor



  • Manufacturer code: 30415252
  • Recommended Battery: 3-4S LIPO
  • KV: 1100KV
  • No-load Current: 3.7A/14.8V
  • Internal resistance: 14.08mΩ
  • Number of slot poles: 12N14P
  • Maximum continuous current: 82.4A/2min15s
  • Maximum continuous power: 1218.9W/2min15s
  • Motor Size: Φ35.1 *66mm
  • Shaft Diameter: 5mm
  • Bearing model: 685ZZ（D11*d5*5）
  • Phase cable: 16AWG
  • Cable Length: 110mm
  • Base thread: Φ16mm-2xM3/Φ19mm-2xM3
  • Motor Weight: 175.8g



Recommend configuration (not included):

  • ESC: Skywalker 80A
  • propeller:
  • 4S：10x5E，11x5.5E
  • 3S:11x5.5E，12x6E,13x6.5E

Clip mounting hole thread: Φ15mm-3*M2.5
Base thread: Φ19mm-2*M3/Φ25mm-2*M3

share


    • 1 x motor Skywalker 2826SL
    • 1 x accessory bag
  • Domestic Shipping starts at $0.00 for this item plus $5.00 for each additional item . International Shipping starts at $5.00 for this item plus $5.00 for each additional item. Shipping availability to your country and Total Shipping will be finalized at check out.
